{"id":1868415664217,"title":"MidNite Solar Circuit Breaker 80A 150VDC 2 Pole DIN Mount - MNEPV80","handle":"mnepv-80a-pv-breaker","description":"\u003cdiv class=\"ui-tabs-panel ui-corner-bottom ui-widget-content\" id=\"tabs-1\" role=\"tabpanel\" aria-hidden=\"false\" aria-labelledby=\"ui-id-1\"\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cspan\u003eThe MidNite Solar MNEPV80 is a high-amperage polarized din rail mount circuit breaker designed for robust overcurrent protection in photovoltaic systems. Rated for 150VDC with a 10,000 AIC interrupt capacity, this wide-body breaker (1 inch \/ 26mm) is engineered to break the full rated load at the rated voltage repeatedly with NO DAMAGE. It is ideal for battery bank disconnects, large inverter inputs, high-current combiners, and main DC load protection.\u003c\/span\u003e\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003e\u003cspan\u003eKey Features \u0026amp; Benefits\u003c\/span\u003e\u003c\/h3\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003eHigh 80A Current Capacity:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Perfect for battery bank disconnects, large inverter DC inputs (e.g., 4-8kW inverters), main PV array combiners, and high-current DC load panels.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003e150VDC Rating:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Suitable for 12V, 24V, and 48V battery-based systems as well as medium-voltage PV arrays, offering flexibility across a range of applications.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003eHeavy-Duty 1-Inch (26mm) Width:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Wider body than standard 13mm breakers, designed to handle higher currents and accommodate larger wire sizes up to 2 AWG.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003eRepeated Load Breaking Capability:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Built to break the full rated load at rated voltage repeatedly with no damage, unlike standard breakers not designed for solar applications.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003e100% Rated Current in MidNite Enclosures:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Can be used at full rated current (80A) without derating when mounted in a MidNite Solar enclosure.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003e10,000 AIC Interrupt Capacity:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e High interrupting capacity provides robust protection against fault currents.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003ePolarized for DC Safety:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Engineered specifically for DC applications with proper polarity orientation, ensuring safe and reliable interruption of DC current.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003eETL Listed for US \u0026amp; Canada:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e When used in MidNite Solar enclosures, this breaker maintains its North American listings and safety certifications.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003eIndoor Installation (Type 1):\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Rated for indoor use in dry locations, suitable for load centers, combiners, and equipment rooms.\u003c\/span\u003e\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003e\u003cspan\u003eTechnical Specifications\u003c\/span\u003e\u003c\/h3\u003e\n\u003cdiv class=\"ds-scroll-area ds-scroll-area--show-on-focus-within _1210dd7 c03cafe9\"\u003e\n\u003ctable\u003e\n\u003cthead\u003e\n\u003ctr\u003e\n\u003cth\u003e\u003cspan\u003eSpecification\u003c\/span\u003e\u003c\/th\u003e\n\u003cth\u003e\u003cspan\u003eDetail\u003c\/span\u003e\u003c\/th\u003e\n\u003c\/tr\u003e\n\u003c\/thead\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eModel\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003eMNEPV80\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eAmperage\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003e80A\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eVoltage Rating\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003e150VDC\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003ePoles\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003e1\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eWidth\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003e1 inch (26mm)\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eMounting Type\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003eDin rail\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eInterrupt Capacity (AIC)\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003e10,000A\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eWire Size Range\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003eUp to 2 AWG\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eTorque Value\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003e20 In-Lbs (2.3NM)\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eEnvironmental Rating\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003eType 1 (Indoor)\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003ePolarization\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003ePolarized\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eListings\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003eETL listed for US \u0026amp; Canada when used in MidNite Solar enclosures\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003c\/div\u003e\n\u003chr\u003e\n\u003ch3\u003e\u003cspan\u003eImportant Technical Notes\u003c\/span\u003e\u003c\/h3\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003eMidNite vs. CBI Breakers:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e MNEPV breakers are the same as CBI QY breakers, except the standard used for CBI is inadequate for the solar industry. MidNite breakers have been evaluated by ETL to 150VDC and are listed for US and Canada. Breakers ordered under the CBI part numbering system will not be listed for 150VDC and in many cases are not suitable for solar applications.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003e100% Rated Current:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e All MidNite circuit breakers can be used at 100% rated current when mounted in a MidNite enclosure.\u003c\/span\u003e\u003c\/p\u003e\n\u003c\/div\u003e","published_at":"2018-11-22T11:25:16-07:00","created_at":"2018-11-22T11:25:16-07:00","vendor":"Midnite Solar","type":"Breakers \u0026 Fuses","tags":["All products","DC Breakers","Electrical Parts","feed-sl-9","Type_Breakers and Fuses"],"price":6500,"price_min":6500,"price_max":6500,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":18342642581593,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"OUTB-00306","requires_shipping":true,"taxable":false,"featured_image":null,"available":true,"name":"MidNite Solar Circuit Breaker 80A 150VDC 2 Pole DIN Mount - MNEPV80","public_title":null,"options":["Default Title"],"price":6500,"weight":227,"compare_at_price":null,"inventory_management":"shopify","barcode":"","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}],"images":["\/\/www.solarpanelstore.com\/cdn\/shop\/products\/mnepv80-100_83597ab6-2531-4e16-bbc3-9767434053b9.jpg?v=1542913020"],"featured_image":"\/\/www.solarpanelstore.com\/cdn\/shop\/products\/mnepv80-100_83597ab6-2531-4e16-bbc3-9767434053b9.jpg?v=1542913020","options":["Title"],"media":[{"alt":"MidNite Solar Circuit Breaker 80A 150VDC 2 Pole DIN Mount - MNEPV80","id":514791506060,"position":1,"preview_image":{"aspect_ratio":0.372,"height":325,"width":121,"src":"\/\/www.solarpanelstore.com\/cdn\/shop\/products\/mnepv80-100_83597ab6-2531-4e16-bbc3-9767434053b9.jpg?v=1542913020"},"aspect_ratio":0.372,"height":325,"media_type":"image","src":"\/\/www.solarpanelstore.com\/cdn\/shop\/products\/mnepv80-100_83597ab6-2531-4e16-bbc3-9767434053b9.jpg?v=1542913020","width":121}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003cdiv class=\"ui-tabs-panel ui-corner-bottom ui-widget-content\" id=\"tabs-1\" role=\"tabpanel\" aria-hidden=\"false\" aria-labelledby=\"ui-id-1\"\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cspan\u003eThe MidNite Solar MNEPV80 is a high-amperage polarized din rail mount circuit breaker designed for robust overcurrent protection in photovoltaic systems. Rated for 150VDC with a 10,000 AIC interrupt capacity, this wide-body breaker (1 inch \/ 26mm) is engineered to break the full rated load at the rated voltage repeatedly with NO DAMAGE. It is ideal for battery bank disconnects, large inverter inputs, high-current combiners, and main DC load protection.\u003c\/span\u003e\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003e\u003cspan\u003eKey Features \u0026amp; Benefits\u003c\/span\u003e\u003c\/h3\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003eHigh 80A Current Capacity:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Perfect for battery bank disconnects, large inverter DC inputs (e.g., 4-8kW inverters), main PV array combiners, and high-current DC load panels.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003e150VDC Rating:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Suitable for 12V, 24V, and 48V battery-based systems as well as medium-voltage PV arrays, offering flexibility across a range of applications.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003eHeavy-Duty 1-Inch (26mm) Width:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Wider body than standard 13mm breakers, designed to handle higher currents and accommodate larger wire sizes up to 2 AWG.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003eRepeated Load Breaking Capability:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Built to break the full rated load at rated voltage repeatedly with no damage, unlike standard breakers not designed for solar applications.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003e100% Rated Current in MidNite Enclosures:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Can be used at full rated current (80A) without derating when mounted in a MidNite Solar enclosure.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003e10,000 AIC Interrupt Capacity:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e High interrupting capacity provides robust protection against fault currents.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003ePolarized for DC Safety:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Engineered specifically for DC applications with proper polarity orientation, ensuring safe and reliable interruption of DC current.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003eETL Listed for US \u0026amp; Canada:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e When used in MidNite Solar enclosures, this breaker maintains its North American listings and safety certifications.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003eIndoor Installation (Type 1):\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e Rated for indoor use in dry locations, suitable for load centers, combiners, and equipment rooms.\u003c\/span\u003e\u003c\/p\u003e\n\u003chr\u003e\n\u003ch3\u003e\u003cspan\u003eTechnical Specifications\u003c\/span\u003e\u003c\/h3\u003e\n\u003cdiv class=\"ds-scroll-area ds-scroll-area--show-on-focus-within _1210dd7 c03cafe9\"\u003e\n\u003ctable\u003e\n\u003cthead\u003e\n\u003ctr\u003e\n\u003cth\u003e\u003cspan\u003eSpecification\u003c\/span\u003e\u003c\/th\u003e\n\u003cth\u003e\u003cspan\u003eDetail\u003c\/span\u003e\u003c\/th\u003e\n\u003c\/tr\u003e\n\u003c\/thead\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eModel\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003eMNEPV80\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eAmperage\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003e80A\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eVoltage Rating\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003e150VDC\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003ePoles\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003e1\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eWidth\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003e1 inch (26mm)\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eMounting Type\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003eDin rail\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eInterrupt Capacity (AIC)\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003e10,000A\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eWire Size Range\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003eUp to 2 AWG\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eTorque Value\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003e20 In-Lbs (2.3NM)\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eEnvironmental Rating\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003eType 1 (Indoor)\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003ePolarization\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003ePolarized\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003e\u003cstrong\u003e\u003cspan\u003eListings\u003c\/span\u003e\u003c\/strong\u003e\u003c\/td\u003e\n\u003ctd\u003e\u003cspan\u003eETL listed for US \u0026amp; Canada when used in MidNite Solar enclosures\u003c\/span\u003e\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e\n\u003c\/div\u003e\n\u003chr\u003e\n\u003ch3\u003e\u003cspan\u003eImportant Technical Notes\u003c\/span\u003e\u003c\/h3\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003eMidNite vs. CBI Breakers:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e MNEPV breakers are the same as CBI QY breakers, except the standard used for CBI is inadequate for the solar industry. MidNite breakers have been evaluated by ETL to 150VDC and are listed for US and Canada. Breakers ordered under the CBI part numbering system will not be listed for 150VDC and in many cases are not suitable for solar applications.\u003c\/span\u003e\u003c\/p\u003e\n\u003cp class=\"ds-markdown-paragraph\"\u003e\u003cstrong\u003e\u003cspan\u003e100% Rated Current:\u003c\/span\u003e\u003c\/strong\u003e\u003cspan\u003e All MidNite circuit breakers can be used at 100% rated current when mounted in a MidNite enclosure.\u003c\/span\u003e\u003c\/p\u003e\n\u003c\/div\u003e"}
